QuiqLiteX Dual White LED (plastic nylon housing)

Name: QuiqLiteX Dual White LED (plastic nylon housing)
SKU: Q-XWW
Price: 41.95 USD
Availability: InStock

$41.95

5 Modes: White LED: 20/40/75/150 Lumens, Safety Strobe: 75 Lumens

QuiqLiteX High Power Dual White LED is USB rechargeable and provides from 20 up to 150 Lumens of light on demand. The Dual White LED configuration is designed for normal reading, writing and maneuvering in the dark without having to hold a flashlight in your hands. QuiqLiteX Dual White LED allows for single or dual LED activation for situations when extra light is required. The first push of the On/Off button will activate a single white LED at 20 Lumens to help preserve your night vision. If more light is required, simply push the X-BOOST button to increase up to 75 Lumens per LED. The QuiqLiteX is equipped with a 10 minute auto-off battery saving timer and continuous Safety Strobe mode, plus QuiqFlare which provides visibility from over 1 mile away. Now includes a new Pupil Gauge located on the back of the QuiqLiteX.

QuiqLiteX Dual White LED

PRODUCT FEATURES

USB Rechargeable
5 Modes: White LED: 20/40/75/150 Lumens, Safety Strobe: 75 Lumens
Super-Bright Dual LEDs
Power X-Boost Button
Dual Switch Technology
Independent LED Activation
Anti-Glare Visor
10 Minute Auto-Off Timer
180 Degree Adjustable Light Arm
360 Degree Rotating Removable Magnetic Clip
Weather Resistant Nylon Housing
QuiqFlare Light Diffuser Attachment
New Pupil Gauge
CE Certified

INCLUDED IN BOX

QuiqLiteX
Removable Magnetic QuiqClip
QuiqFlare Attachment
USB Charging Cord
User Manual

Weight	9 oz
Dimensions	9 × 6 × 2 in

MODES

White LED Mode

1st push: activates single White LED at 20 Lumens (10 minute auto-off timer)
2nd push: activates dual White LEDs together at 40 Lumens (10 minute auto-off timer)
3rd push: turns all LEDs off

X-Boost LED Mode

1st push of X-Boost button located on the back of the product will increase brightness from 20 up to 75 Lumens per LED (150 Lumens if dual LED mode is active)
2nd push will dim light back down to 20 Lumens per LED

Safety Strobe

Press & hold main power button down for 2 seconds to activate strobe
(no auto-off timer)
Press button again to turn off strobe

How To Wear

SHIRT WEARING INSTRUCTIONS

REMOVE QuiqClip. Slide the clip off product in a downward motion.
Clip QuiqLiteX into the shirt pocket fabric between the main body and shirt pocket clamping slot.
Cover top of QuiqLiteX with pocket lapel.

MOLLE WEARING INSTRUCTIONS

REMOVE QuiqClip. Slide the clip off product in a downward motion.
Activate On/Off button between MOLLE webbing loops.

The QuiqClip can be re-attached for thicker mounting applications up to 1" thick including gun belts, cite books, sun visors, jacket, hat, etc. The QuiqClip is magnetic and will hold to most metallic objects.

QuiqLite in Shirt Pocket

REMOVE CLIP FIRST
* QuiqLite shown for illustration. Actual product may vary.

QuiqLite in Molle

REMOVE CLIP FIRST
* QuiqLite shown for illustration. Actual product may vary.

Charging

QuiqLiteX uses a micro USB charging port located on the side of the product. Insert the supplied micro USB charging cord into the side of the QuiqLiteX and plug directly into a computer USB port, or other micro USB port with a minimum output of 5 volts.

CHARGING - Red LED is steady
CHARGED - Red LED is flashing

Charge time is approximately 2 hours

SPECIFICATIONS

LOW POWER LED: 20 Lumens (30 hours)
DUAL LED: 40 Lumens (15 hours)
X-BOOST LED: 75 Lumens (5 hours)
X-BOOST DUAL LED: 150 Lumens (2.5 hours)
STROBE: 75 Lumens (5 hours)
HOUSING: Nylon/Aluminum
BATTERY: 1 QuiqLiteX Lithium (included) Part# 052042
CHARGE TIME: 2.5 hours or less
LENGTH: 3″
WIDTH: 0.90″
WEIGHT: 1.4 oz. (w/ battery & clip)

Product Manual

Thank you for selecting QuiqLiteX concealed hands-free illumination products for professionals.

QuiqLiteX is USB rechargeable delivering from 20 up to150 lumens of light on demand. Manufactured from high strength nylon plastic and aluminum QuiqLiteX will take an assortment of punishment and will provide years of dependable service.

Please read this manual before using your QuiqLiteX. It includes important safety and operating instructions and should be saved. QuiqLiteX must be fully charged before first use. If you have any questions regarding our products, please contact us at: info@quiqlite.com or call us toll free at: 1-866-496-2506

WEARING INSTRUCTIONS:

Slide clip off product in a downward motion (#1)
Clip QuiqLiteX into the shirt pocket fabric between the main body and shirt pocket clamping slot (#2)
QuiqLiteX is also designed to securely fit into MOLLE webbing loops on all Law Enforcement and Military tactical vests (clip removed.)
Cover top of X with pocket lapel.
Activate On/Off button through fabric of shirt pocket or between MOLLE webbing loops.
Activate turbo/dimmer button located on the top of the product
Re-attach clip for thicker mounting applications up to 1” thick i.e. Gun Belt, Cite book, sun visor, jacket, etc.

BATTERY RUN TIME:

Low Power: 40 Lumens (10 hours)
X-BOOST Medium Power: 75 Lumens (4 hours)
X-BOOST High Power: 150 Lumens (2 hours)
Safety Strobe: 75 Lumens (4 hours)

CHARGING INSTRUCTIONS:

QuiqLiteX uses a micro SD charging port located on the bottom / underside of the product. Insert the supplied micro SD charging cord into the side of QuiqLiteX and plug charger directly into wall. It may take a few seconds for the charging (red) L.E.D. to light when the cord is first inserted. QuiqLite X can also be charged: in your vehicle power outlet with a USB adaptor, or USB computer port via USB to Micro SD charging cable (not provided).

Charging….L.E.D. is solid Non Blinking
Charged…L.E.D. flashing
Charge time is approximately 2 hours

CAUTION: To reduce the risk of fire, electrical shock or personal injury, do not attempt to use the supplied charger to recharge any other product. Do not abuse the charging cord.

Plug AC charger directly into an electrical outlet. Do not use and extension cord
Do not try to repair the unit yourself. Send it to a qualified service facility or return it to the factory.
Use of this product for other than a lighting device is not recommended
QuiqLite disclaims liability for other than recommended use.

FUNCTIONS:

1st push activates dual white LEDs at 20 Lumens
2nd push turns off white LEDs
(20-minute auto off timer)

Boost Mode:

With both LEDs On, quickly double push On/Off button to increase Lumens from 20, 75 up to 100 lumens.
Double push again and X will reduce back down to 20 Lumens
QX will reset to 20 Lumens when QX is turned off
(20-minute auto off timer)

Strobe Function:
